SPECIFICATIONS
AI Functions: Motion Detection
Alarm Action: FTP Photo,Email Photo
Audio Output: None
Brand Name: HQCAM
Certification: CE
Color: black
Color Night Vision: No
Compression Forma: Advanced H.265/H.264 video compression
Connectivity: IP/Network Wired
Dimensions (L x W x D)(mm): 40*40mm
High Definition: None
High-concerned chemical: None
Housing Material: Aluminum-alloy Metal
IR Distance(m): 10,1-10 meter
Installation: Embedded
Internal Storage: None
Lens (mm): 0MM
Lens Quantity: Single Lens
Megapixels: 8MP
Minimum Illumination(Lux): 0.001Lux F1.2
Model Number: 8mp ip camera
Operating Temperature: -10°-60°
Optional POE: 48V
Origin: Mainland China
Power Consumption(W): 12V2A(Not included Power Supply )
Power Supply: Normal
Power Supply(V): DC12V
Sensor: CMOS
Sensor Brand: Omnivision
Shell Material: Metal
Smart home platform: Other
Special Features: MINI
Specific: IR-CUT filte
Style: Mini Camera
Style1: Ip Camera
Style2: Cctv Camera
Style3: Security Camera
Style4: Surveillance Camera
Style5: Video Surveillance
Style6: Surveillance
Style7: ip camera poe
Style8: ip camera indoor
Style9: 940nm LED hid den
Supported Mobile Systems: Android,iOS
Supported Operating Systems: Windows XP,Windows Vista
TF Card: None
Video Compression Format: H.264,H.265
Viewing Angle : 150°
Zoom: None
Zoom type: None
is_customized: Yes
8MP 4K Feature
Supporting Face detection, Humanoid detectionn, and supports customization of other smart functions;
8.0MP HD Black light illumination resolution, clear and fine images;
Support 2D/3D noise reduction, digital wide dynamic;
Advanced H.265(Compatible with H.264) video compression, Super low rate, high definition quality of image;
Professional anti-lightning, conform to GB/T17626.5 and IEC61000-4-5;
Support ONVIF, access third party;
Support various mobile monitoring(iPhone, Android);
Different angle lens available
120 degree lens is 2.1mm, and the standard configuration is 3.6mm lens, about 90 degrees
Hid-den infrared lamp
940nm infrared lamp, invisible light source to human eyes, no harm to birds and animals, very hid-den
OS | Parameters | 4K 8MP |
kernel | System |
|
Processor | Mstar | |
Video | Image sensor | 8MP Super Low illuminance COMS image sensor |
Video Codec | H.265 main profile and baseline | |
LEN |
| |
IR LED | 10pcs 940nm LED | |
IR distance | 1-10M | |
Support mobile phone | All phone | |
P2P | PHONE,IE,P2P Client global Internet | |
Video Resolution | First stream:4K 8MP(3840*2160)@15fps/5MP(2880*1624)@25fps/4MP(2560*1440)@25fps/ 3MP(2304*1296)@25fps/2MP(1920*1080)@25fps can be set | |
4K 8MP(3840*2160) | ||
Second stream:1280*720,800*448,704*576,640*360 | ||
Three stream:640*360/352*288 | ||
frame rate | 8MP:15fps,5MP:25fps,4MP:25fps,3MP:25fps,2MP:25fps | |
Video compression | 32Kbits/S～12280Mbits/S | |
Min.Lux | Color>0.01 LUX B&W<0 LUX | |
Store | SD card | NA |
Client/Browser | Support | |
Record | Client | support |
Browser | Support | |
SD CARD | not Support | |
Playback | Client | support |
Browser | Support | |
SD CARD | not support | |
SD Card |
| not support SD card |
| ||
Audio | Audio input | Mic is builded in camera |
Audio output | SNA | |
Audio Codec | G.726/G.711 | |
Internet | Internet face | 10Base-T/100Base-TX, POE |
Network Protocol | TCP/IP,https,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP | |
Access Protocol | ONVIF | |
Alarm | Motion detection | At most 4 respective regions |
Alarm linkage | Alarm picture send E-mail, alarm images upload FTP server | |
Snap | Time snap | Regular support capturing images to the FTP server |
safe | User management | Provide three levels of rights management (admin, user, guest), support to modify login user name and password |
Other | Inter Power,consumption | DC12V 2A/POE (The package does not provide a power adapter) |
Working temperature | -40℃ ～ +55℃ | |
Working Humidity | 10-95% | |
