SPECIFICATIONS
5MP senor: 6.0megapixel. Low Lux CMOS
AI Functions: Motion Detection
App name: Smart Life
Audio Output: 1CH RCA
Brand Name: HQCAM
Camera Stabilization: None
Certification: CE
Color: green
Color Night Vision: No
Connectivity: Closed System/CCTV Wireless
High Definition: 1080P(Full-HD)
High-concerned chemical: None
IP Rating: Other
IR Distance(m): 1-6,5
Installation: Embedded,Side,Normal,Wall Mounted,Pendant Mount
Internal Storage: None
Lens (mm): 3.6mm
Lens Quantity: Single Lens
Megapixels: 6mp
Minimum Illumination(Lux): 0.01lux
Operating Temperature: -10°-60°
Origin: Mainland China
P2P: support
PC: support pc /mobile view
Power Consumption(W): 12v 2a
Power Mode: Mains Electricity
Power Source: Normal
Power Supply: Normal
Power Supply(V): 12V,DC12V2A
Scene: Indoor
Sensor: CMOS
Sensor Brand: SmartSens
Shell Material: Metal
Smart home platform: Tuya
Special Features: Vandal-proof
Style: Mini Camera
Supported Mobile Systems: Android,iOS
Supported Operating Systems: Windows XP,Windows 7,Windows 8,Windows 10
TF Card: None
Video Compression Format: H.264,H.265
Viewing Angle : 90°
Zoom: None
Zoom type: None
app: TUYA OR Smart life
for: Look at the bird inside the cage wifi Ip Camera AUDIO
is_customized: Yes
item: wifi POE Mini Ip Camera
night vision: yes
support: wifi & IR 940nm&sd card storage &phone watch ,on vif,P2P support audio
tf card slot: max128gb
NOTICE:
Our IP Camera DO NOT Included The Power Adapter,
If You Need It, Please Kindly Click The Photo As Below, Add It In Your Order List, Thanks !
For more power extension cables and network cables, please click the link below to purchase
Attenation:
camera come with 940nm ir leds default
Support Tuya Smart APP and Smart Life APP
This camera can support Tuya Smart or Smart Life APP. It works with other smart devices in your home that can support Tuya Smart APP.
This is a prime lens with a fixed focal length. When you find the picture is blurry and unclear, you can slowly turn the lens (to the left or right) and stop when the picture becomes clear.
Real test photos for 2.8mm lens
6MP camera was installed in the "birdcage" to take photos
The size of the "birdcage" is 27x18x13cm
Take photos indoors
Photos of other cases
Lens description（From a 4MP camera test）
3.6mm is approximately 90 degrees
2.8mm is approximately 100 degrees
2.1mm is approximately 110 degrees
1.7mm is approximately 175 degrees
Photos of other guests after installation are displayed
940nm infrared lamp
940nm infrared lamp, invisible light source to human eyes,
Access the camera interface through a browser:
The username is admin and the password is 123456
SIZE:
The 4MP WIFI POE version supports both wifi and POE power supply and complies with IEEE 802.3af and 802.3at
The 6MP WIFI POE version supports both wifi and POE power supply and complies with IEEE 802.3af and 802.3at
1/3" 6MP Low Lux CMOS with Fullhan 3K DSP;
support IR Led, warm LED, dual LED;
H.265+H.264 video coding,
support humanoid detectionand frame remark,
support dual streams, mainstream is 3200*1800, sub-stream is D1,
support full net-com and ONVIF.
With 0.5T Algorithms,more accurate.
Support 2.4G&5G dual band wifi, bluetooth insert.
Features :
1. HD lens 2.8mm lens
2. Style:
3. Night vision distance is 1-5 meters
4. H.265 Video compression
5. 2-way talk(optional)
6. TCP + WiFi for network connection
7. APP: Tuya Smart or Smart life
8. Support TF card( up to 128GB) / cloud storage
The mobile phone scans the QR code to download the "tuya or smart life " app; the Android phone can download "tuya Pro" in the application market such as App Store. The iOS system phone can download "tuya " in the App Store.
Cloud Service
1. After buying the cloud storage service, all alarms and videos will be saved on the cloud server and can be downloaded or viewed online. When sending the alarm information, you can select not only photos to view but also one-key playback of the cloud alarm video. If you do not buy the cloud storage service, you need to go to the SD card to retrieve the alarm video.
2.Cloud service buy and binding/unbinding
(According to your personal needs, buy the cloud storage package service you need, and redeem the coupon code at the bottom of the page.)
Continuous Recording:Recording 24 hours a day;
3.Video quality:You can choose "HD"or"SD"
Why choose it? Tuya Smart /Smart Life App covers various smart fields, involving home appliance, smart switches,security & sensors, exercise & health, video surveillance cameras, gateway etc., With it, you can control everything just by one App. Don't need install many App for different devices in smartphone. You can say goodbye thoroughly to such trouble of full screen App
