FX1N-Compatible PLC Board Options

Develop a compatible ladder-logic control project with a PLC board offered in MR and MRT output configurations.

✅ Build control around ladder logic - The board supports the described GX programming workflow for a compatible project.

✅ Choose outputs for the application - MR and MRT selections provide different relay and pulse-output arrangements.

✅ Connect for programming and monitoring - An RS232 port supplies the described communication path to compatible host equipment.

Match the controller to the machine's signals

A PLC project begins with the inputs, outputs and behaviour the machine needs. Select the board configuration around that list, then develop and test the ladder program before connecting the controlled equipment.

MR and MRT versions differ, including the arrangement of Y0 and Y1 on the pulse-capable versions. Check the exact terminal map, supply and load ratings for the chosen board rather than treating every selection as interchangeable.

This is a controller board for integration, not a complete enclosed or safety-rated control system. Provide the appropriate power supply, isolation, protective circuitry and installation measures for the application.

Technical details

• Type: FX1N-style programmable controller board
• Selections: 24MR, 24MRT, 30MR, 30MRT, 32MR or 32MRT
• Programming connection: RS232
• Dimensions described: 122 × 87 × 42 mm
• Mounting-hole spacing: 115 × 80 mm
• Exact I/O and electrical limits depend on selected version

Select the controller configuration that fits your automation design.
