AHD/TVI/CVI/CVBS Video Converter - HDMI and VGA

View a compatible analogue camera feed on an HDMI display without replacing the camera. This AHD41 converter accepts AHD, TVI, CVI and CVBS video input and provides selectable 720p or 1080p HDMI output for a more practical viewing connection.

✅ Bridge camera and display connections - Convert compatible analogue camera video into an HDMI display signal.

✅ Use several camera signal formats - AHD, TVI, CVI and CVBS input support accommodates different analogue systems.

✅ Select the HDMI output resolution - A button switches between the supported 720p and 1080p output modes.

Give an Existing Camera a New Display Connection

An analogue camera feed and a modern monitor do not always share the same connection. A converter sits between them, translating the supported camera signal so you can use an HDMI screen for viewing.

The unit recognises compatible input formats automatically and provides controls for output selection. CVBS output is also available; VGA requires an additional external module that is not included, so choose the connection that fits your planned display.

Technical details

• Model: AHD41 series
• Inputs: AHD, TVI, CVI and CVBS
• HDMI output: 720p or 1080p
• Power input: DC 5-20 V
• Dimensions: approximately 66 × 53 × 21 mm
• Includes: converter, 12 V power adapter and manual
• VGA module: purchased separately

Connect your compatible camera feed to an HDMI display with the AHD41 converter.
